SFF-MSL - semi-automatic strap feeder

Semi-automatic strapping arch for steel, PP & PET straps SFF-MSL

Semi-automatic machine with steel construction and movable lower part of arch for strapping around the packaged item on the palletThe machine feeds steel or plastic (PP, PET) straps. There is usually used battery or pneumatic hand strapping tool. There are added input & output conveyors and turntable with the conveyor.

  • Significantly increases the efficiency of strapping and occupational safety
  • There is needed only one operator for strapping of larger objects
  • Very simple operation



Technical parameters
Modification
Accessories
Packing material
Inquiry

Technical parameters

ordering code 600 000919
dimension (l x w x h) 4300 x 4700 x 2300 mm
machine weight 350 kg
noise level of machine 78 dB
max. machine capacity 20 - 25 cycles/min.
conveyor height 160 mm
max. packing width 1 200 mm
max. packing height 1 500 mm
supply voltage 400 V / 50 Hz
power input 1 kW
strap - material steel
strap width 10 - 20 mm
strap thickness 0,6 - 1 mm
inner diameter of roll 270 - 310 / 400 (PP, PET) mm
outer diameter of roll 600 mm
max. loading 500 kg

Standard modifications

SFF - semi-automatic strap feeder

SFF - semi-automatic strap feeder
  • strap width - 10 - 20 mm
  • for steel, PP and PET strap
  • increase in strapping efficiency
  • very easy operation

Recommended accessories

Action

ZAPAK ZP90 - battery strapping tool for PP, PET

ZAPAK ZP90 - battery strapping tool for PP, PET
  • strap width 9 - 13 mm
  • 18V Li-Ion battery
  • more efficient brushless motor
  • higher battery capacity
Action

ZAPAK ZP93 - battery strapping tool for PP, PET

ZAPAK ZP93 - battery strapping tool for PP, PET
  • strap width 9 - 16 mm
  • 18V Li-Ion battery
  • more efficient brushless motor
  • higher battery capacity
Action

ZAPAK ZP97 - battery strapping tool for PP, PET

ZAPAK ZP97 - battery strapping tool for PP, PET
  • strap width 15 - 19 mm
  • 18V Li-Ion battery
  • more efficient brushless motor
  • higher battery capacity

ZAPAK ZP28-6A - pneumatic strapping tool

ZAPAK ZP28-6A - pneumatic strapping tool
  • strap width - 13 - 16 mm
  • pneumatic
  • high tightening power (3500 N)
  • stable working, high lifetime

ZAPAK ZP28-9A - pneumatic strapping tool

ZAPAK ZP28-9A - pneumatic strapping tool
  • strap width - 16 - 19 mm
  • pneumatic
  • high tightening power (3500 N)
  • stable working, high lifetime

BO-7PN - pneumatic sealless steel strapping tool

BO-7PN - pneumatic sealless steel strapping tool
  • strap width - 13 - 20 mm
  • sealing method - sealless
  • pneumatic tightening
  • patented system of punching

FP-32S pneumatic strapping tool

FP-32S pneumatic strapping tool
  • strap width - 32 mm
  • sealing method - seal type F
  • double notching of the seal
  • max. strength of joint 15000N

FPZ-32 pneumatic strapping tool

FPZ-32 pneumatic strapping tool
  • strap width - 32 mm
  • sealing method - seal type F
  • double notching of the seal
  • max. strength of joint 15000N

Binding and packaging materials

PP (polypropylen) strap 12 x 0,50 mm, 400/180 - 3000 m, 1300 N, black

PP (polypropylen) strap 12 x 0,50 mm, 400/180 - 3000 m, 1300 N, black
  • width 12 mm, thickness 0,50 mm
  • black color
  • strenght 1300 N
  • tube 400 mm, roll 3000 m

PP strap 15 x 0,65 mm, 400/180 - 1500 m, 2200 N, black

PP strap 15 x 0,65 mm, 400/180 - 1500 m, 2200 N, black
  • width 15 mm, thickness 0,65 mm
  • black color
  • strenght 2200 N
  • tube 400, roll 1500 m

PP strap 15 x 0,80 mm, 400/150 - 1500 m, 2700 N, black

PP strap 15 x 0,80 mm, 400/150 - 1500 m, 2700 N, black
  • width 15 mm, thickness 0,80 mm
  • black color
  • strenght 2700 N
  • tube 400 mm, roll 1500 m

PET strap 12 x 0,60 mm, 406/145 - 2500 m, 2600 N, green

PET strap 12 x 0,60 mm, 406/145 - 2500 m, 2600 N, green
  • width 12 mm, thickness 0,60 mm
  • green color
  • strenght 2600 N
  • tube 406 mm, roll 2500 m

PET strap 15,5 x 0,70 mm, 406/145 - 1750 m, 3860 N, green

PET strap 15,5 x 0,70 mm, 406/145 - 1750 m, 3860 N, green
  • width 15,5 mm, thickness 0,70 mm
  • green color
  • strenght 4500 N
  • tube 406 mm, roll 1750 m

PET strap 16 x 0,80 mm, 406/145 - 1200 m, 5200 N, EMBOSS 20%

PET strap 16 x 0,80 mm, 406/145 - 1200 m, 5200 N, EMBOSS 20%
  • width 16 mm, thickness 0,80 mm
  • green color
  • strenght 5200 N
  • tube 406 mm, roll 1200 m

PET strap 16 x 1,00 mm, 406/145 - 1200 m, 5700 N, green, EMBOSS 15%

PET strap 16 x 1,00 mm, 406/145 - 1200 m, 5700 N, green, EMBOSS 15%
  • width 16 mm, thickness 1,00 mm
  • green color
  • strenght 5700 N
  • tube 406 mm, roll 1200 m

PET strap 19 x 1,00 mm, 406/145 - 850 m, 8000 N, green, EMBOSS 20%

PET strap 19 x 1,00 mm, 406/145 - 850 m, 8000 N, green, EMBOSS 20%
  • width 19 mm, thickness 1,00 mm
  • green color
  • strenght 8000 N
  • tube 406 mm, roll 850 m
