FP-32S pneumatic strapping tool

This pneumatic strapping tool FP-32S is designed for strapping round or irregularly shaped objects with steel strap. The joint is made by double notching the seal. The strapping tool works with strap and steel seal of the widht of 19, 25 or 32 mm according to the modification. Tightening power of this strapping tool is up to 8 000 N and strength of the joint reaches up to 15 000 N. The tool is equipped with pneumatic opening and closing of the sealing slot. This model is intended for the strap of the width of 32 mm.

Technical parameters
Modification
Accessories
Packing material
Spare part
Inquiry

Technical parameters

ordering code 700 001109
sealing method seal type F
strap - material steel
strap width 32 mm
strap thickness 0,8 - 1,2 mm
dimension (l x w x h) 420 x 260 x 190 mm
compressed air 6 - 7 bar
air consumption/cycle 9 l/sec.
weight 10,1 kg
tightening power 9000 N

Standard modifications

FP-19S pneumatic strapping tool

FP-19S pneumatic strapping tool
  • strap width - 19 mm
  • sealing method - seal type F
  • double notching of the seal
  • max. strength of joint 10000N

FP-25S pneumatic strapping tool

FP-25S pneumatic strapping tool
  • strap width - 25 mm
  • sealing method - seal type F
  • double notching of the seal
  • max. strength of joint 12000N

Recommended accessories

KL-1 - steel strap cutter

KL-1 - steel strap cutter
  • for steel straps
  • max. strap size 32 x 1 mm
  • robust cutter
  • holder for precise cutting

KL-2 - heavy duty steel strap cutter

KL-2 - heavy duty steel strap cutter
  • for steel straps
  • max. strap size 50 x 1,2 mm
  • robust lever cutter

OP-28 decoiler for ribbon steel straps

OP-28 decoiler for ribbon steel straps
  • strap width - 25 - 32 mm
  • unlimited inner diameter
  • max. outer diameter - 700 mm
  • robust construction

EW-15 mod. 9340 - spring balancer for loading

EW-15 mod. 9340 - spring balancer for loading
  • max. loading - 10 - 14 kg
  • robust metal model
  • pre-tensioning by screw in axis
  • safety eye for securing

Binding and packaging materials

Steel seals F-32 (32 mm, 207500)

Steel seals F-32 (32 mm, 207500)
  • seal width - 32 mm
  • for steel strap
  • packaging - 300 pcs

32 x 1,0 mm - steel strap (blank, metallic lustre, ribbon)

32 x 1,0 mm - steel strap (blank, metallic lustre, ribbon)
  • width 32 mm, thickness 1,0 mm
  • strenght 22080 N
  • roll weight approx. 41 kgs
  • inside diam. 280 mm
