EXP-108 RW - pallet stretch wrapping machine for wrapping rolls
Automatic wrapping machine EXP-108RW for wrapping rolls or pallets, suitable for operations with medium to large packaging capacity (up to 15 rolls or 30 pallets / hour). The machine is equipped with 3 configurable programs and motorized film pre-stretch with optional 230% or 300% pre-stretch (stretching 1 m of film up to 4 m).
Other equipment of the machine:
- automatic cutting of the film at the end of the packaging cycle
- built-in service diagnostics
- precise oriented stop turntable
- slow start and stop of the turntable
- optical pallet height sensor
- stepless control of the turntable rotation speed and the film carriage travel
- stepless regulation of rollers for roll rotation
- stepless regulation of the tightening force
- adjustable number of film rotations
- programming and communication with the control unit using a mini display and keyboard
Technical parameters
Product videos
Inquiry
Technical parameters
| ordering code | 600 002216 |
| material - foil |
machine stretch |
| max. film dimension (width x diameter) | 500 x 250 mm |
| max. pallet dimensions (L x W) | 1500 x 1500 mm |
| max. wrapping height | 2000 mm |
| min. wrapping diameter | 500 mm |
| max. wrapping diameter | 1800 mm |
| max. length of wrapped object | 1800 mm |
| max. coil weight | 1000 kg |
| film pre-stretch | yes |
| turntable turns | 0 - 8 turns/min. |
| turntable diameter | 2140 mm |
| turntable height | 400 mm |
| supply voltage | 230V / 50Hz |
| power input | 1,6 kW |
| ambient temperature | 0 - 45 °C |
| dimension (l x w x h) | 3778 x 2300 x 2345 mm |
| machine weight | cca 800 kg |
